Industrial-Giredhi reLCD Ratidza: A Practical Specification Guide for 6 Key Industries

Industrial-Giredhi vs. Commercial LCD: Chii Chacho Chinodiwa NeGap

Industrial-giredhi ichikamu cheinjiniya, kwete chekushambadzira. Tafura iri pazasi inopfupikisa misiyano inoyerika pakati pemapanera akavakirwa nharaunda dzevatengi anodzorwa neayo akagadzirirwa chaiyo-kutumirwa kwemaindasitiri pasi rose.

Yekutengesa yekutarisa inomhanya pa60℃inosvibisa backlight yayo mukati memwedzi. A 300-nit panel inonyangarika muchiedza chezuva. Iyo yekubata interface inotadza kuburikidza nemagurovhosi idambudziko rekuchengetedza pane yekugadzira pasi. Iyo gaka remutengo wehardware pakati pezvekutengesa uye maindasitiri mapaneru anogara ari madiki pane yakadzika mutengo wekutadza kwemunda mune yekugadzira sisitimu kana yakadzorwa mudziyo. Kunzwisisauko zvisungo zvekuratidza zvekutengesa zvinova dambudziko rinoshandainhanho yekutanga yekutsanangura imwe nzira yakanaka.

Maindasitiri matanhatu anoenderana neindasitiri-Giredhi LCD Displays

1. Manufacturing uye Industrial Automation

HMI mapaneru, SCADA monitors, uye PLC opareta zviteshi zvinomhanya zvisingaperi munzvimbo dzinobatanidza tembiricha dzakasimudzika, mhepo inobhururuka, mhute inotonhorera, uye kunoramba kuchiita vibration. Chikanganiso chinonyanyozivikanwa muchikamu chino ndechekudzikisira tembiricha: chipani chakatemerwa mamiriro emuhofisi - kazhinji 0 dhigirii kusvika 50 madhigirii - anozokundikana nguva isati yakwana pamagadziro ekugadzira anogara asvika 55–65 madhigirii pedyo nekupisa{7}}kugadzira michina. Vashandi vanopfeka magurovhosi ePPE vanoda ma touch interfaces anopindura nekuvimbika, uye ambient mwenje inogona kusiyanisa zvakanyanya pakati penzvimbo. Zvekutarisisa kweiripo LCD kuratidza masisitimu enzvimbo dzeindasitiri, huwandu hwemafomu zvinhu zvinogadzirisa zvinonyanya kuzivikanwa HMI uye control panel application.

• Kupenya:300-500 nits shoma; kumusoro pedyo nemafashama emwenje kana mahwindo
• Kushanda tembiricha:−20 dhigirii kusvika 70 dhigirii
• Dziviriro:IP54 kana yepamusoro kune yakavhurika fekitori nharaunda
• Bata:Resistive kana girovhosi-compatible projected capacitive (PCA)
• Simba rekuisa:Yakakura-ranji DC (9–36V) yekuenderana nemagetsi emuindasitiri

2. Zvishandiso zvekurapa uye zvehutano

Midziyo yekuvhiya, mamonitor evarwere, pombi inosanganisirwa nepombi, nenzvimbo-ye{1}}ye{1}}yezvishandiso zvekutarisisa zvinoisa zvimwe zvezvinhu zvinonyanya kudiwa zvekuratidzira pane chero chikamu. Nzvimbo yacho inofanira kuramba ichibviswa utachiona nechipatara-magiredhi emishonga - isopropyl alcohol, quaternary ammonium compounds - pasina cloudiness yemaziso kana kuparara kwepasi. Anti-mabhachi ekuvheneka akakosha pasi pe-kusimba pamusoro pechiedza chekuvhiya. Mune zvigadziriso zvisina hutachiona, kushanda kwegirovhosi{10}}hakugoneki{11}}kutaurirana.

Imwe poindi inowanzo furatirwa padanho rekugadzira: iyo LCD module pachayo haina chitupa chekurapa mudziyo. IEC 60601-1 kutevedzera kunoshanda kune chapera chigadzirwa. Chiratidziro chinofanirwa kusarudzwa uye kunyorwa nenzira yekuteerera kubva pazuva rekutanga - mutengesi asingakwanise kuburitsa EMC bvunzo mishumo kana zviziviso zvezvinhu zvinononoka kana kukanganisa chitupa padanho rekuongorora, rinova dambudziko rinodhura zvakanyanya pane kusarudza mutengesi akakodzera kare.

• Kupenya:400-700 nits yemamiriro akasiyana ekiriniki emwenje
• Surface treatment:Doro-inodzivirira, -inomira, -inoratidzira
• Bata:Glove-compatible capacitive; kunyatsoita-kugonesa ruoko kwenzvimbo dzekuongorora
• Dziviriro:IP65-yakatemerwa pamberi pepaneru yemidziyo yakafumurwa kune zvinwiwa kana ekuchenesa maajenti
• Zvinyorwa:Yakazara EMC bvunzo mishumo uye RoHS zvinhu zviziviso zvinodikanwa kubva kune mapaneru mutengesi

3. Mota-Yakagadzikwa uye Mafambisirwo Ekufambisa

Fleet telematics panels, zviratidziro zvemutyairi, mu-cab diagnostic masisitimu, uye njanji yeHMI interfaces zvinopa dambudziko rimwe chete rinokosha: kuverenga kwezuva. A 400-nit display inonetsa kuverenga mukombi yemotokari mukati memasikati makuru; pasi pezuva rakananga rezhizha, rinonyatsopera. Pani imwe cheteyo inofanirawo kurarama −30 madhigirii mukutanga kwechando mangwanani uye 80 madhigirii mukati mekabhu yakapakwa muchirimo - kupisa kunopisa kunobvisa zvinhu zvakawanda zvekutengesa. Vibration inowedzera yechitatu yekutadza dimension: loose connectors, akatsemuka majoini ekutengesa, uye delaminated touch layers zvakajairika mumotokari dzinoramba dzichizunguzika. ISO 16750-3 inopa iyo yakakodzera mota yekuongorora nharaunda bhenji. Zvemaapplication anodiwakusimba kwekunze kwekubata sikirini mune-mamo emutraffic, kupenya kwakafanana uye IP kuchengetedza zvinodiwa zvinoshanda.

• Kupenya:700–1,000 nits shoma; 1,500 nits yemapanera akananga kuchiedza chezuva
• Kushanda tembiricha:−30 dhigirii kusvika 80 dhigirii kana yakafara kune yakanyanyisa mamiriro ekunze deployments
• Vibration uye kuvhunduka:Yakaedzwa kune ISO 16750-3 kana yakaenzana yekutakura chiyero
• Dziviriro:IP65 yecab-mapanera akaiswa; IP67 yekumisikidza yakafumurwa zvizere
• Surface:Diffused anti-glare or anti-reflective coating

4. Oiri, Gasi, uye Migodhi

Pombi dzekutarisa zviteshi, makamuri ekudzora ekunze kwemahombekombe, uye midziyo yepasi pevhu yakatarisana nekushanduka kwetembiricha kubva -40 dhigirii kusvika 85 dhigirii, guruva rinoenderera uye hunyoro, kunoramba kuchiita vibration, uye mune dzimwe nzvimbo, mhepo inogona kuputika. Zvemidziyo yakaiswa munzvimbo dzine njodzi - dzinowanikwa muoiri yepamusoro negasi, kugadzira makemikari, uye kumwe kucherwa kwezvicherwa -ATEX dhairekitorimuEurope (IECEx pasirese) chinhu chepamutemo chinodiwa kumusangano wekupedzisira wechigadzirwa. Kusarudzwa kwechikamu pachikamu chemodule yekuratidzira kunofanirwa kutsigira iyo nzira yekuteerera kubva pakutanga kwekugadzira. Zvishandiso zviri muchikamu ichi zvinogara zvichiitwa kwemakore gumi kusvika gumi nemashanu, uye zviyero zvakada kufanana zvezvakatipoteredza zvinoshanda mukudzivirira, uko bvunzo dzeMIL-STD-810 dzinowedzera zvimwe zvinodiwa.

• Kushanda tembiricha:−40 dhigirii kusvika 85 dhigirii yekumisikidza kunze nepasi pevhu
• Dziviriro:IP67 kana IP68 yenjodzi yekunyura kana yakakwira-kushambidzika
• Kutevedzwa kwenzvimbo ine ngozi:ATEX/IECEx-inoenderana sarudzo yenzvimbo dzinoshanda
• Kupenya:500-1,000 nits zvichienderana nekuiswa kwemwenje
• Hupenyu:10–15 makore ekushanda kwemidziyo inoita kuti kusimbiswa kwenguva yakareba-kuwanikwa kwepaneru chinhu chinodiwa pakushanda

5. Retail Kiosks uye Pachako-Matemisheni eSevhisi

Masevhisi-makiosks, nzvimbo dzePOS, michina yekutengera matikiti, uye cheki yemahotera-mumasisitimu ava kutsanangura maindasitiri-magiredhi emagiredhi - kwete nekuda kwemamiriro ekunze, asi maawa ekushanda. Kiosk inomhanya maawa gumi nemana kusvika gumi nematanhatu pazuva, mazuva 365 pagore, inounganidza ingangoita zviuru zvishanu kusvika kumaawa e6,000 ekushanda pagore. Consumer-giredhi remwenje rekumashure rakayerwa chikamu chechikamu chebasa iroro rinodzikira zvinooneka mukati megore rekutanga rekutengesa. Anti-vandal surface treatment inobata munzvimbo dzinoiswa veruzhinji, uye mapaneru eIPS anochengetedza ruvara rwakajeka pamakona akakura ekuona pane mamwe maTN - akakosha kana vatengi vachiuya kubva kureba nemakona akasiyana. Ongorora yedukiosk display rangeuyewega-sevhisi zvigadziriso, kana kuonazvizere wega{{0}sevhisi kiosk deployment gwarakune yakadzama yekuisa uye sarudzo kutungamira.

• Kupenya:500-700 nits yenzvimbo dzakajeka dzekutengesa uye dzekufambisa
• Bata:Projected capacitive with anti-vandal surface treatment
• Dziviriro:IP54 kumberi kwepaneru kushoma kunopesana nekurasa uye vamiririri vekuchenesa
• Kutarisa kona:IPS panel inodiwa kune-mutengi wepakona{1}}akatarisa kuverenga
• Hupenyu:5+ makore akasimbiswa kuvapo kwemaparts atinoenderera mberi

6. Agriculture uye Industrial IoT

Precision irrigation controllers, zvipfuyo zvekutarisa zvipfuyo, uye IIoT edge node dzinowanzoshanda munzvimbo dziri kure dzinenge dzisingakwanisi kuwana sevhisi, zvichiita kuti-kuvimbike kwenguva refu - kwemakore, kwete mwedzi - mutyairi wekugadzira. Midziyo yekurima inotarisana nekupisa kwekushisa, huruva, hunyoro, uye vibration. IIoT node dzinomhanya pasolar kana bhatiri simba rinowedzera yakaderera yekumira yemagetsi mashandisirwo kune rondedzero yezvinodikanwa chaizvo. Equipment service hupenyu hwemakore manomwe kusvika gumi zvinoreva kuti zvisungo zvekuwanikwa kwepaneru zvinotakura huremu chaihwo hwekushanda.Yakabatanidzwa smart LCD kuratidza mhindurokubatanidza simba-magadzirirwo akakodzera ane mwero wezvakatipoteredza zviri kuwedzera kuwanda mune zvekurima nemazvo uye IIoT zvivakwa.

• Kushanda tembiricha:−20 dhigirii kusvika 70 dhigirii kumatunhu ane mwero; yakafara kune mamiriro ekunze akanyanyisa
• Dziviriro:IP65 shoma yenzvimbo-zvishandiso zvakaiswa
• Bata:Glove-inoenderana nenzvimbo dzekurima dzePPE
• Simba:Kupinza kweDC kunoshanda kwezuva kana{0}maapplication ane simba rebhatiri
• Hupenyu:7–10 makore ehupenyu hwesevhisi hunoda kusimbiswa -kwenguva refu yekuwanika kwepaneru

Maitiro ekufananidza LCD Zvinotsanangurwa kune Chikumbiro chako

Chiratidziro chekurudyi handicho chinonyanya kuita-chakazara sarudzo mukatalogi - ndiyo ine tsanangudzo dzinoenderana nemamiriro ekushanda chaiwo. Kushanda kuburikidza nesarudzo shanu munhevedzano kunodzivirira zvinowanzoitika uye zvinodhura zvikanganiso zvekutsanangura.

Danho 1: Nyora mamiriro ekushanda usati waongorora chero chigadzirwa.Tembiricha yemhando, guruva uye kunyorova kuratidzwa, mazinga evibrate, uye ambient mwenje mamiriro anotyaira sarudzo dzakanyanya. Kana yangonyorwa, chirevo chemutengesi chega chega chinogona kuongororwa maererano nezvakanyorwa pane fungidziro yemuromo - uye iro gwaro rinodzivirira sarudzo yeinjiniya yehupenyu hwechigadzirwa.

Danho 2: Seta kupenya kunoenderana nemamiriro emwenje chaiwo, kwete zvakanakisa-sefungidziro.Indoor inodzorwa nharaunda kazhinji inoda 300-500 nits. Chiedza chakasimba che ambient - pasi rezvitoro, nzvimbo dzefekitari pedyo nemahwindo, makombi emotokari - kazhinji anoda 500–800 nits. Chiedza chezuva chakananga chinoda hushoma hwe1,000 nits. Kumaapplications uko pane pane fomu yefomu chinhu chakakosha pamwe nekupenya, kuenzanisa pakatiLCD uye LED bar skrini mafomuinovharira-zvazvinoita.

Nhanho 3: Sarudza tekinoroji yekubata kuti uenderane neanoshanda chaiwo uye mamiriro.Resistive touch inoshanda nemagirovhosi, maoko akanyorova, uye zvinyoreso - zvinovimbika munzvimbo dzine tsvina kana PPE-inodiwa, asi pakubata kamwe chete-. Projected capacitive (PCP) inopa kujeka kwemufananidzo uye kuwanda-kutsigirwa kwekubata negirovhosi-inoenderana nepamusoro sarudzo, asi haina kuvimbika kana yakasvibiswa zvakanyanya. Mutungamiriri wedu kuizvo zvimisikidzo zvinonyatsoenderana akasiyana touchscreen tekinorojiinopa hwaro hwekutanga hunoshanda hwesarudzo iyi.

Danho 4: Wona kuti-nguva yakareba iripo yekutenga usati wazvipira.Mapaneru evatengi anowanzo miswa pasina yambiro mukati memwedzi gumi nemaviri kusvika gumi nemasere kubva pakatangwa. Midziyo yeindasitiri inomhanya kwemakore gumi kana kupfuura. Bvunza zvakananga: chii chakazvipira hupenyu hwechigadzirwa, chii magumo{{4}ye-yewindo reziviso yehupenyu, uye pane-nguva yekupedzisira{7}}kutenga? Kune B2B sarudzo dzekutenga pachiyero, seiB2B kiosk inoratidza kutenga uye kugadzirisainoshanda - kusanganisira zvinyorwa zvinodikanwa zvehupenyu - zvinogadzirisa zvinotarisirwa.

Nhanho yechishanu: Ziva zvinodikanwa zvetifiketi padanho rekugadzira, kwete nhanho yekuteerera.Zvigadzirwa zvekurapa zvinoda IEC 60601-1 zvinyorwa kubva kumutengesi wekuratidzira. Midziyo yenzvimbo ine ngozi-inoda ATEX kana IECEx zvinyorwa. CE, FCC, uye UL zvitupa zvinofanirwa kuchinjika-zvichipesana nezviripo zvekuyedza mishumo yekutanga. Kuwana gaka rezvinyorwa padanho rekuteedzera rekuongorora kunodhura zvakanyanya pane kuridzivirira mukugadzira. Yeduyakazara kuratidza chigadzirwa renjiinonyora zvitupa zviripo nemodhi.

Mibvunzo Inowanzo bvunzwa

Ndeipi iyo yakaderera IP chiyero chekunze kwemaindasitiri kuratidza?

IP65 inopa dziviriro yakakwana kubva kuguruva uye kubva kumvura inoyerwa kubva kune chero divi - iyo inoshanda pasi pemapaneli ekunze anonaya kana paipi-inocheneswa pasi. IP67 inowedzera dziviriro kusvika pakunyura kwechinguva, zvinova zvakafanira kushandiswa kwemvura mugungwa uye nzvimbo dzekugadzira chikafu dzine simba guru-kudonha. Kune chero kuisirwa kwekunze pasina imwe yekudzivirira yakavharirwa, IP65 inofanirwa kubatwa sedikidiki inogamuchirwa yakatarwa, kwete iyo inotarirwa.

Ko yekutengeserana yekutarisa inogona kushandiswa munzvimbo yeindasitiri?

Pamabasa akareruka-ane tembiricha inodzorwa, maawa ekushanda akajairwa, uye kuratidzwa kushoma kweguruva kana mwando, hardware yekutengeserana inogona kukwana. Munzvimbo dzine tembiricha yakanyanyisa, kuenderera mberi 24/7 kushanda, kuzunguzika kwakakosha, kana kugezeswa nguva dzose, zviratidziro zvekutengesa zvinombotadza zvisati zvapedza chigadzirwa chimwe chete chechirongwa cheindasitiri. Musiyano wemitengo pakati penzvimbo yekutengeserana neyemaindasitiri hauwanzo kururamisa njodzi yenguva isina kurongeka mukugadzirwa kana kudzorwa mamiriro.

Ndeupi musiyano unoshanda pakati peresistive uye capacitive kubata kwekushandiswa kwemaindasitiri?

Resistive panels anopindura zvigunwe zvegirovhosi, maoko akanyorova, uye zvinyoreso - zvinovimbika mutsvina, nyoro, kana PPE-inodiwa nharaunda, asi inongogumira pakubata kamwe chete-. Mapurojekiti ane capacitive mapanera anopa mufananidzo kujeka uye akawanda-rutsigiro rwekubata negirovhosi{5}}nzvimbo dzinoenderana dziripo, asi dzinonzwa zvakanyanya kusvibiswa. Pakukumbira-mumba, kurapwa, kana{8}}kunangana nemutengi{8}kukachena, capacitive ndiyo sarudzo yakanaka; kuitira kushandiswa kwekunze kwemunda, kugadzira, uye{9}}nzvimbo dzine tsvina dzakakwirira, kudzivirira kunovimbika zvakanyanya.

Magetsi -egiredhi eLCD ekumashure anogara kwenguva yakareba sei?

Maindasitiri-magiredhi ebacklight assemblies anowanzo ratirwa kwemaawa 50,000 kana kudarika. Pamaawa masere ekushanda kwezuva nezuva, izvo zvinoshandura kusvika kumakore gumi nemanomwe ehupenyu hwebasa rebacklight. Panel-kuwanikwa kwechikamu kubva kumakambani anogadzira maLCD anowanzo kupihwa kwemakore mashanu kana kudarika, uye kupera kuri pamutemo-kwe{8}}kwenguva yeziviso yehupenyu kuti ipe nguva-yekupedzisira{10}}yekuronga kutenga - pundutso ine mutsindo pamusoro pemapanera evatengi, ayo anogona kumiswa pasina chiziviso mukati megore rimwe kusvika maviri.

Kana iwe uri mumatanho ekutanga esarudzo yekuratidzira,svika zvakananganemashoko ako ekushandisa uye nharaunda yekushanda zvinodiwa. Nezve-zvakajairwa fomu factor application, yedubha{{0}yakaita LCD skrini renjiinovharira magadzirirwo anoenderana nesherufu-mupendero, dashboard yemotokari, uye zvigadziriso zvezviridzwa zvisingatarisirwe nekatalog panel.
